M6 Class Pleated Air Filter for Industrial Ventilation System 305×610×292mm
GRF-JSK-HEPA-SP1
Specification:305x610x292mm
Filter grade:M6
Dielectric material: Fiberglass
Filter grade:M6
Dielectric material: Fiberglass
Quantity:
This HVAC Separator Filter/ Cartridge Air Filter is an essential component for system efficiency. Its pleat design defines it as a high-performance HVAC Separator Filter that fits perfectly with a Cartridge Air Filter housing. Using this HVAC Separator Filter significantly extends the lifespan of the downstream Cartridge Air Filter and other equipment. Rely on this quality HVAC Separator Filter and Cartridge Air Filter pairing for superior air quality.
Temperature: 260°C maximum continuous, 360°C peak during 1 hour
| Model | Filtration Class | Dimensions WxHxD (mm) | Air Flow/pressure drop (m³/hr/Pa) | Media area (m²) | Weight (kg) |
| GRF-JSK-HEPA-SP1 | M6 | 305x610x292 | 1700/80 | 7.8 | 6 |
| GRF-JSK-HEPA-SP2 | M6 | 610x610x292 | 3400/75 | 16 | 9.5 |
| GRF-JSK-HEPA-SP3 | M6 | 610x610x150 | 1700/30 | 8 | 5.5 |
| GRF-JSK-HEPA-SP4 | M6 | 305x610x78 | 750/30 | 2.5 | 2 |
| GRF-JSK-HEPA-SP5 | M6 | 610x610x78 | 1500/30 | 5 | 4 |
| GRF-JSK-HEPA-SP6 | F8 | 305x610x292 | 1700/120 | 7.8 | 5.5 |
| GRF-JSK-HEPA-SP7 | F8 | 610x610x292 | 3400/110 | 2.5 | 9.5 |
| GRF-JSK-HEPA-SP8 | F8 | 610x610x150 | 1700/65 | 5 | 5.5 |
